Product Details:
Place of Origin: Jiangsu, China
Brand Name: YongJie
Contact Now
Detailed Product Description
Plastic Processed: HDPE, HDPE/PP, PE/PP, Lldpe, PP, MLLDPE, LDPE Output (kg/h): 30 - 80 Kg/h
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Core Components: PLC, Gearbox, Motor Screw Design: Double
Voltage: 380V 50HZ Dimension(l*w*h): Model
Power (kw): 22 Warranty: 1 Year
Twin Screw Type: Co-rotating Parallel Twin-screw Screw L/D Ratio: 40:1
Screw Speed (rpm): 50 - 600 Rpm Color: Any Color As Your Require
RPM ( R/min): 600r/min Torque(N.m): 115N.M
T/N: 4.2 Inverter: ABB Brand
Motor Brand: Siemens Beide Vacuum Degassing: 0.75kw
Screen Changer Type: Manual Function: Plastic Compounding
Pelletizing Type: Strand Type, Die Face Type Marketing Type: Hot Product 2019
Condition: New Warranty Of Core Components: 1 Year
Type: Water Cooling Strand Showroom Location: None
Applicable Industries: Manufacturing Plant Screw Diameter (mm): 35.6
Weight: 8000

Mini plastic granules making machine plastic extrusion equipment



                 The company concentrated on research development and manufacturing “high level, accurate, highly sophisticated series product —Co-rotating parallel “cordwood” twin screw extruder. We have provided customer first-class products with strong torque, high production, energy conservation and environmental protection products.

          Taking advantage of oneself technical force we can formulate the typical technical proposal for the customer; to helping fulfill design, equipment process, engineering installation, and testing from raw material storage bin to finished product packing of the whole production line.

                                      Model           Diameter(mm)                                         L/D          RPM ( r/min)                             Power   (Kw)   Torque(N.m)                                       T/N                                  Capacity (Kg/h)
SJSL-20 20 32-44 600 5.5 30 4.8 6.5-15
SJSL-36 36 32-48 600 15 115 4.2 30-75
SJSL-51A 51 32-52 500 45 405 5.1 100-200
SJSL-51B 51 32-52 600 55 415 5.2 150-25
SJSL-63A 63 32-62 400      55        620       4.4      160-250
500 75 675 4.8 200-300

SJSL-63B

63 32-64 600     90       675       4.8       225-375
800 110 620 4.4 300-500
SJSL-75A 72 32-64 400     90        1015    4.7       225-350
500 110 1005 4.6 300-550
SJSL-75B 72 32-64 600     132       990      4.6       400-650
800 160 900 4.2 480-800
SJSL-92A 92 32-64 400     250 2815    5.9       650-1050
500 2250 4.7 750-1250
SJSL-92B 92 32-64 600     280 2365    5.0       900-1500
800 2250 4.7 1200-2000
SJSL-135A 135 32-48 400 315 6190 4.6 1500-2500
SJSL-135B 135 32-48 500 400 6750 5.1 200-3500

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 0

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 2

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 4

Water trough

SJSL20:1-2m

SJSL-36/51:3m

SJSL-63A/75A:4m

SJSL-75B/95:5/6m



Mini Plastic Granules Making Machine Plastic Extrusion Equipment 6

Blowing dryer

SJSL-20: 1.5kw

SJSL-36/51: 1.5kw

SJSL-75A/63A:2.2kw

SJSL-75B/95:3kw,4kw



Mini Plastic Granules Making Machine Plastic Extrusion Equipment 8

Pelletizer

SJSL-20: 50kg/h 0.75kw

SJSL-36:100kg/h 2.2kw

SJSL-51/63A: 300kg/h  4kw

SJSL-63B/75A: 500kg/h  5.5kw

SJSL-75B/95:1000kg/h

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 10

Application for water-cooling strand



1.    Fiber reinforcement and modification: filling glass fiber or carbon fiber for: PP, PA, PBT,

       ABS, AS, POM, PPS, PET, etc.



2.    Ploymer compounding: PC+ABS, PA+ABS,CPE+ABS,PP+EPDM,PA+EPDM,

       PA+SBS, etc.



3.   Filling modified: Filling CaCO3,Talc,Titanium, carbon black for PVC PE,PP, EVA etc.



4.   Cable material: cable sheath, cable insulation compounds, crosslinking compounds,

      optical fiber protection compounds, cable coating material, thermal contraction material,

      etc.



5.   Dedicated material: PPR pipe compounds, PE crosslinking tube material, cigarettes

      filter tip material, acetate fiber material, etc.



6.   High Concentration Color Masterbatch: PE,ABS,PS,EVA,PET,PP + color +

      additives, etc.



7.   Flaming Retardants: PVC, PP, PA, ABS, EVA, PBT + flame retardants, etc.



8.   Special Functional Masterbatch: double protection masterbatch, antistatic masterbatch,

      anti-bacteria masterbatch, thermal insulation masterbatch, hypothermia material, etc.



9.   The degradable masterbatch: PP, PE, PS + starch+ additives, etc.

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 12Mini Plastic Granules Making Machine Plastic Extrusion Equipment 14Mini Plastic Granules Making Machine Plastic Extrusion Equipment 16

Mini Plastic Granules Making Machine Plastic Extrusion Equipment 18



FAQ



1. Are you a factory or trading company?



     Both.

2. Where is your factory located? How can I visit there?



   Our factory is located in industrial centralized area of Moling town, Jiangning, Nanjing, China.



   (1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;



   (2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in             the railway station.



3. What's your advantages?



   (1) Excellent quality control



   (2) First-class service



   (3) Professional Tech. and R&D team



   (4) Quick manufacturing time



   (5) Quite competitive price



4. How long is the delivery time?



    Under normal conditions, products are delivered within 35 days.



5. How can I know the stauts of my order?



    We will send you photos and videos of your order at different satge in time and keep you informed of the latest information.



6. how long is the warranty?



    We can offer one-year warranty for the whole machine.
