Name: Competitive-price Granulator Extruder Plastic Injection Granule Making Machine
Brand: Nanjing Yongjie Qixin Machinery Equipment Co., Ltd.
Availability: InStock

Home Products Water strand pelletizing line

Competitive-price Granulator Extruder Plastic Injection Granule Making Machine

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Yongjie

Contact Now

Detailed Product Description

Plastic Processed:	HDPE, HDPE/PP, PE/PP, Lldpe, Polystyrene, ABS/PP, PP, MLLDPE, LDPE, ABS, PET, PC	Output (kg/h):	300 - 500 Kg/h
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Core Components:	PLC, Gearbox, Motor	Screw Design:	Double
Voltage:	380V 50hz Or Customized	Dimension(lwh):	3032.6
Power (kw):	90	Warranty:	1 Year
Twin Screw Type:	Co-rotating Parallel Twin-screw	Screw L/D Ratio:	44:1
Screw Speed (rpm):	50 - 600 Rpm	Color:	Custmoized
Application:	Plastic Raw Material Compounding And Granulating	Cutting Way:	Air Strand
Screw Material:	38CrMoAlA	Motor Brand:	Siemens Beide
Process Type:	Extrusion And Pelletizing	Inverter:	ABB
Barrel Material:	38CrMoAlA	Torque Of Screw:	1200*2 T(N.m)
Temperature Controller:	RKC	Marketing Type:	New Product 2020
Condition:	New	Warranty Of Core Components:	1 Year
Type:	Granulating Production Line	Showroom Location:	None
Applicable Industries:	Manufacturing Plant	Screw Diameter (mm):	62.4
Weight:	4500

Competitive-price granulator extruder plastic injection granule making machine

Product Description

Nanjing Yongjie bio plastic machine is the special and innovative technique for the production of biodegradable pellet , like PBAT, PLA, PVA, PBS, PCL etc with corn starch, cassava starch, potato starch, and hgih-quality plastics pellets, which have low viscosity and high elasticity, or have special shape, such as micro-particle.

Typical Application: 1. blowing film: PVA+starch cold or hot water soluable film, shopping bag etc, PBAT+PLA+starch for biodegradable or compostable film

2. PLA+starch for injection or thermoforming of food containers, cups, forks etc 3. PLA+starch for extrusion of drinking straw etc.

Models avaialbe for granulator extruder plastic injection granule making machine

Image & Data

1. Machine Parts of granulator extruder plastic injection granule making machine Name: Twin-screw extruder Brand: YJ Motor: AC motor, power:75KW, brand: SIEMENS Bade, Speed governing: Japanese ABB inverter control speed, Revolutions:50-600rpm Reduction ratio: i = 2.5:1
	1.1. Main Parts of granulator extruder plastic injection granule making machine Name: Gearbox Brand: YJ Parallel tri-axial structure is combination of reduction and matrix. The gear is made of high quality alloy (20CrNi2Mo).Drive bearing: The brand of axletree: Japanese NSK. Lubrication: Gear bearings in the gear box will be of oil immersed. There is hydraulic lubrication in the gear engagement and gear bearings. Cooling: Lubricated cooling adopts shell and tube cooler and circulated water cooling method.
1.2. Main Parts of granulator extruder plastic injection granule making machine Name: Screw Brand: YJ Direction of rotation: co-rotating; The screw elements material is W6Mo5Cr4V2(6542#) The core axis is made of high quality alloy steel 40CrNiMo
	2.3. Main Parts of granulator extruder plastic injection granule making machine Name: Barrel Brand: YJ Diameter:62.4mm Standard: L/D: 40:1, and other available Length: 10 sections for 40:1, 10240mm=2400mm Material: made of 45# forged steel* with the abrasion-resistant alloy 101(Ni-Fe-Cr-W) inside, which is smooth and abrasion resistant. The hardness is HRC60-64

Company Information

Nanjing Yongjie Qixin Machinery Equipment Co., Ltd, founded in 2001, covers an area of 20,000 square meters on our own land, with yearly output of plastic extruder more than 200 sets.

Our company is committed to the research and production of single screw extrusion production line, co-rotating parallel twin screw extrusion and granule machine, tandem compounding system for extruding and granulating, twin screw extruding line for plate, profile, and automatic production line for waste film(bottle) smashing, cleaning, recycling and re-granulating etc.From the very beginning of the firm, quality is put in the first place, and our factory is certificated to CE and ISO9001:2008.

Our projects

Our Services

Pre-sales service
♦1. Inquiry and consulting support.
♦2.Selecting economical and suitable extruder and related machines for customers.
♦3.Providing technical details of machine.
♦4.Providing means of trial performance for customer.

♦5.Factory tour & assistance of invitation letter when needed.
Sales service
♦1.Recommending engineering conditions required for installation.
♦2.Communicating on time the manufacturing status of machines.
After-sales service
♦1. Engineers available to service machinery overseas in installation, commissioning and training.
♦2.Filing in detail customer’s order information.
♦3.Providing long-term maintenance service and spare parts.
♦4.Giving technical support to customer for developing new product.
♦5.Providing free maintenance for a year.

Packaging & Shipping

Contact Information

Nanjing Yongjie Qixin Machinery Equipment Co.,Ltd
Add. : No.9 Lanxia Road, Moling Industrial Concentration Area, Jiangning District,211165, Nanjing, China
Tel.: 0086 25 52750152
Fax: 0086 25 58736139

Contact person:Annie
Mob/whatsapp/Line/Wechat:0086 15026670964
Skype: annie at njyjhg.com(same as email)
Website: www.njyjhg.com
