Name: Promotion Plastic Pellet Making Machine Twin Screw Extruder
Brand: Nanjing Yongjie Qixin Machinery Equipment Co., Ltd.
Availability: InStock

Home Products Water strand pelletizing line

Promotion Plastic Pellet Making Machine Twin Screw Extruder

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	YongJie

Contact Now

Detailed Product Description

Plastic Processed:	HDPE, HDPE/PP, PA, PE/PP, Lldpe, ABS/PP, PP, MLLDPE, LDPE, PC	Output (kg/h):	300 - 500 Kg/h
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Core Components:	PLC, Gearbox	Screw Design:	Double-screw
Voltage:	380V 50HZ	Dimension(lwh):	MODEL
Power (kw):	110	Warranty:	1 Year
Color:	Any Color As Your Require	RPM( R/min):	400/500/600/800
Torque(N.m):	1015/1005/990/900	T/N:	4.7/4.6/4.2
Inverter:	ABB Brand	Motor:	Siemens Beide
Vacuum Degassing:	Included	Automatic Screen Changer:	Included
Solenoid Valve:	Danfoss	Water Tank:	4000mm
Marketing Type:	Hot Product 2019	Condition:	New
Warranty Of Core Components:	1 Year	Type:	Recycling Granulator
Showroom Location:	None	Applicable Industries:	Manufacturing Plant
Weight:	8000

Promotion plastic pellet making machine twin screw extruder

Brief introduction: plastic pellet making machine twin screw extruder water strand pelletizing line is extrusion strand pelletizing, consisting of parallel twin-screw extruder and corresponding auxiliary granulation.

The gearbox is high torque design, implement smooth operation, low noise.

Apply to: Masterbatch and regenerationof PP,PE,PET,PS,ABS,PA,PVC,PC,POM,EVA,PMMA

Model	Diameter(mm)	L/D	RPM ( r/min)	Power (Kw)	Torque(N.m)	T/N	Capacity (Kg/h)
SJSL-20	20	32-44	600	5.5	30	4.8	6.5-15
SJSL-36	36	32-48	600	15	115	4.2	30-75
SJSL-51A	51	32-52	500	45	405	5.1	100-200
SJSL-51B	51	32-52	600	55	415	5.2	150-25
SJSL-63A	63	32-62	400	55	620	4.4	160-250
SJSL-63A	63	32-62	500	75	675	4.8	200-300
SJSL-63B	63	32-64	600	90	675	4.8	225-375
SJSL-63B	63	32-64	800	110	620	4.4	300-500
SJSL-75A	72	32-64	400	90	1015	4.7	225-350
SJSL-75A	72	32-64	500	110	1005	4.6	300-550
SJSL-75B	72	32-64	600	132	990	4.6	400-650
SJSL-75B	72	32-64	800	160	900	4.2	480-800
SJSL-92A	92	32-64	400	250	2815	5.9	650-1050
SJSL-92A	92	32-64	500	250	2250	4.7	750-1250
SJSL-92B	92	32-64	600	280	2365	5.0	900-1500
SJSL-92B	92	32-64	800	280	2250	4.7	1200-2000
SJSL-135A	135	32-48	400	315	6190	4.6	1500-2500
SJSL-135B	135	32-48	500	400	6750	5.1	200-3500

Application for plastic pellet making machine twin screw extruder:

1. Master batch and color master batch:

PP/PE/ABS+Caco3/Sio2(silicon dioxide)/talc(chalk)/carbon black

2. PP/PA/PA3/PA66/PA10/PA1012/ABS/PBT/PET/POM+glass fiber/carbon Fiber/iron fiber

3. PBT, PET recycling

4. EVA

Auxiliary

Water trough

SJSL20:1-2m

SJSL-36/51:3m

SJSL-63A/75A:4m

SJSL-75B/95:5/6m

Blowing dryer

SJSL-20: 1.5kw

SJSL-36/51: 1.5kw

SJSL-75A/63A:2.2kw

SJSL-75B/95:3kw,4kw

Pelletizer

SJSL-20: 50kg/h 0.75kw

SJSL-36:100kg/h 2.2kw

SJSL-51/63A: 300kg/h 4kw

SJSL-63B/75A: 500kg/h 5.5kw

SJSL-75B/95:1000kg/h

Other product

Water-ring Hot-face pelletizing line Pelletizing in the water line

Air-cooling hot-face pelletizing line Air-cooling strand pelletizing line

FAQ

1. Are you a factory or trading company?

Both.

2. Where is your factory located? How can I visit there?

Our factory is located in industrial centralized area of Moling town, Jiangning, Nanjing, China.

(1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;

(2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in the railway station.

3. What's your advantages?

(1) Excellent quality control

(2) First-class service

(3) Professional Tech. and R&D team

(4) Quick manufacturing time

(5) Quite competitive price

4. How long is the delivery time?

Under normal conditions, products are delivered within 35 days.

5. How can I know the stauts of my order?

We will send you photos and videos of your order at different satge in time and keep you informed of the latest information.

6. how long is the warranty?

We can offer one-year warranty for the whole machine.
