Home ProductsCorn Starch biodegradable plastic machine

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine

  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
  • Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Yongjie
Certification: CE,ISO
Contact Now
Detailed Product Description
Plastic Processed: PLA/PBAT/PVA+starch Output (kg/h): 300 - 500 Kg/h
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Core Components: PLC, Gearbox, Motor Screw Design: Double
Voltage: 380V/440V/415V/customized Dimension(l*w*h): 20*3*2.5
Power (kw): 132 Warranty: 12 Months
Twin Screw Type: Co-rotating Parallel Twin-screw, Co-rotating Parallel Twin-screw Screw L/D Ratio: 48:1, 48:1
Screw Speed (rpm): 50 - 500 Rpm Application: Corn Starch Bio Plastic Pellets
Raw Material: Corn Starch, Pla Or Pbat Barrel Material: 38CrMoAlA
Cutting Way: Air Strand Screw Material: 38CrMoAlA
Motor Brand: Siemens Beide Process Type: Extrusion And Pelletizing
Barrel Diameter: 71.8mm Inverter: Sweden ABB
Condition: New Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year Type: Granulating Production Line
Showroom Location: None Applicable Industries: Manufacturing Plant
Screw Diameter (mm): 71, 71 Weight: 7000

corn starch compostable & biodegradable twin screw extruder bio plastic pellets machine

Product Description

 Nanjing Yongjie bio plastic pellets machine factory is the special and innovative technique for the production of biodegradable pellet , like PBAT, PLA, PVA, PBS, PCL etc with corn starch, cassava starch, potato starch, and hgih-quality plastics pellets, which have low viscosity and high elasticity, or have special shape, such as micro-particle.

Typical Application:1.Polyolefine:LLDPE, LDPE, HDPE, PP, EPDM...2.Styrolpolymere:PS, ABS... 3.Acrylharze:PMMA...4.Polyacetale:POM...5.Polycarbonate:PC,PET,PBT, PE...

6.Polyamide:PA6,PA6.6,PA11,PA12...7.Thermoplastics Elastomer:TPE,TPV,TPR,TPEE...8.Hot melt adhesives: TPU, EVA, PA, PP 9. PBAT, PLA, PVA, PBS, PCL with corn starch cassava starch, potato starch etc



Models avaialbe for bio plastic pellets machine

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 0

Image & Data

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 2



 Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 4



Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 6





1. Machine Parts of  corn starch compostable & biodegradable twin screw extruder bio plastic pellets machine

Name: Twin-screw extruder
Brand: YJ
Motor: AC motor, power:75KW, brand: SIEMENS Bade,
Speed governing: Japanese ABB inverter control speed,
Revolutions:
50-600rpm
Reduction ratio: i =
 2.5:1

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 8

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 10

1.1.  Main Parts of corn starch compostable & biodegradable twin screw extruder bio plastic pellets machine

Name: Gearbox
Brand: YJ
Parallel tri-axial structure is combination of reduction and matrix. The gear is made of high quality alloy (20CrNi2Mo).Drive bearing: The brand of axletree: Japanese NSK.
Lubrication: Gear bearings in the gear box will be of oil immersed. There is hydraulic lubrication in the gear engagement and gear bearings.
Cooling: Lubricated cooling adopts shell and tube cooler and circulated water cooling method.

1.2. Main Parts of corn starch compostable & biodegradable twin screw extruder bio plastic pellets machine

Name: Screw
Brand: YJ
Direction of rotation: co-rotating;

The screw elements material is W6Mo5Cr4V2
(6542#)
The core axis is made of high quality alloy steel 40CrNiMo





Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 12

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 14

2.3. Main Parts of corn starch compostable & biodegradable twin screw extruder bio plastic pellets machine

Name: Barrel
Brand: YJ
Diameter
:62.4mm
Standard: L/D: 40:1, and other available
Length: 10 sections for 40:1, 10*240mm=2400mm

Material: made of 45# forged steel with the abrasion-resistant alloy 101(Ni-Fe-Cr-W) inside, which is smooth and abrasion resistant. The hardness is HRC60-64













Company Information



Nanjing Yongjie Qixin Machinery Equipment Co., Ltd, founded in 2001, covers an area of 20,000 square meters on our own land, with yearly output of plastic extruder more than 200 sets.

Our company is committed to the research and production of single screw extrusion production line, co-rotating parallel twin screw extrusion and granule machine, tandem compounding system for extruding and granulating, twin screw extruding line for plate, profile, and automatic production line for waste film(bottle) smashing, cleaning, recycling and re-granulating etc.From the very beginning of the firm, quality is put in the first place, and our factory is certificated to CE and ISO9001:2008.

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 16



Our projects

 Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 18

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 20

Our Services



Pre-sales service
♦1. Inquiry and consulting support.
2.Selecting economical and suitable extruder and related machines for customers.
3.Providing technical details of machine.
4.Providing means of trial performance for customer.

5.Factory tour & assistance of invitation letter when needed.
Sales service
1.Recommending engineering conditions required for installation.
2.Communicating on time the manufacturing status of machines.
After-sales service
1. Engineers available to service machinery overseas in installation, commissioning and training.

2.Filing in detail customer’s order information.
3.Providing long-term maintenance service and spare parts.
4.Giving technical support to customer for developing new product.
5.Providing free maintenance for a year.

Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 22

Packaging & Shipping



Corn Starch Compostable & Biodegradable Twin Screw Extruder Bio Plastic Pellets Machine 24
