Place of Origin: | Jiangsu, China |
Brand Name: | YongJie |
Certification: | CE ISO9001 |
Plastic Processed: | PP/PVC/WPC/PE/ABS/XPS/Polystyrene | Application: | Granules |
---|---|---|---|
Screw Design: | Double-screw | Twin Screw Type: | Co-rotating Parallel Twin-screw |
Screw Material: | W6Mo5Cr4V2 | Screw Diameter (mm): | 50.5 |
Screw L/D Ratio: | 40:1 | Screw Speed (rpm): | 600 Rpm |
Voltage: | 380V 50HZ | Dimension(l*w*h): | Model |
Power (kw): | 55 | Warranty: | 1 Year |
Key Selling Points: | Automatic | Video Outgoing-inspection: | Provided |
Core Components: | Motor, PLC, Gearbox | Machinery Test Report: | Provided |
Color: | Any Color As Your Require | T/N: | 5.9/4.7/5.0 |
Capacity (Kg/h): | 650-2000kg/h | Torque(N.m): | 2815/2250/2365/2250 |
Usage: | Plastic Compounding | Inverter: | ABB |
Motor: | Siemens Beide/WN/WEG | Temperature Control Meter: | OMRON Or RKC |
Final Product: | Plastic Pellet, Granules | Automatic Grade: | High Level |
After-sales Service Provided: | Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
Local Service Location: | Viet Nam, Brazil, India, Mexico | Marketing Type: | New Product 2020 |
Condition: | New | Showroom Location: | None |
Applicable Industries: | Manufacturing Plant | Warranty Of Core Components: | 1 Year |
Weight: | 1t-10t |
Brief introduction: Water ring cover is aluminum casting, precision machining of internal flow channel and thickness of water, the distance of cooling material is long, can effectively avoid secondary adhesion.
Apply to: The production of high-quality mixing and plastic granulation.
Model |
Diameter (mm) |
L/D |
RPM (r/min) |
Power (Kw) |
Torque (N.m) |
T/N |
Capacity (Kg/h) |
SJSL-20 | 20 | 32-44 | 600 | 5.5 | 30 | 4.8 | 6.5-15 |
SJSL-36 | 36 | 32-48 | 600 | 15 | 115 | 4.2 | 30-75 |
SJSL-51A | 51 | 32-52 | 500 | 45 | 405 | 5.1 | 100-200 |
SJSL-51B | 51 | 32-52 | 600 | 55 | 415 | 5.2 | 150-25 |
SJSL-63A | 63 | 32-62 | 400 | 55 | 620 | 4.4 | 160-250 |
500 | 75 | 675 | 4.8 | 200-300 | |||
SJSL-63B |
63 | 32-64 | 600 | 90 | 675 | 4.8 | 225-375 |
800 | 110 | 620 | 4.4 | 300-500 | |||
SJSL-75A | 72 | 32-64 | 400 | 90 | 1015 | 4.7 | 225-350 |
500 | 110 | 1005 | 4.6 | 300-550 | |||
SJSL-75B | 72 | 32-64 | 600 | 132 | 990 | 4.6 | 400-650 |
800 | 160 | 900 | 4.2 | 480-800 | |||
SJSL-92A | 92 | 32-64 | 400 | 250 | 2815 | 5.9 | 650-1050 |
500 | 2250 | 4.7 | 750-1250 | ||||
SJSL-92B | 92 | 32-64 | 600 | 280 | 2365 | 5.0 | 900-1500 |
800 | 2250 | 4.7 | 1200-2000 | ||||
SJSL-135A | 135 | 32-48 | 400 | 315 | 6190 | 4.6 | 1500-2500 |
SJSL-135B | 135 | 32-48 | 500 | 400 | 6750 | 5.1 |
200-3500 |
Application for water-ring hot face production line
1. Filling master batch: PE, EVA, etc. + caco3, talc, filling modified and carbon black etc.
2. LDPE, HDPE, LLDPE, MDPE, drivepipe, insulation material, crosslinking material,
cable coating material , thermal contraction pipe material.
3. PPR pipe compounds, PE crosslinking tube material, TPR, TPU thermoplastic
elastomer, EVA and hot melt additives.
4. Color mater batch: PE, ABS, PS, EVA master batch, etc.
5. ABS, EVA flaming retarding master batch, etc.
6. PE, PP, PS filling and biodegradable masterbatch, etc.
Auxiliary
Water-ring cover |
|
pelletizer |
|
Centrifugal dehydrator |
|
Vibrating sieve |
|
Bin |
|
FAQ
1. Are you a factory or trading company?
Both.
2. Where is your factory located? How can I visit there?
Our factory is located in industrial centralized area of Moling town, Jiangning, Nanjing, China.
(1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;
(2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in the railway station.
3. What's your advantages?
(1) Excellent quality control
(2) First-class service
(3) Professional Tech. and R&D team
(4) Quick manufacturing time
(5) Quite competitive price
4. How long is the delivery time?
Under normal conditions, products are delivered within 35 days.
5. How can I know the stauts of my order?
We will send you photos and videos of your order at different satge in time and keep you informed of the latest information.
6. how long is the warranty?
We can offer one-year warranty for the whole machine.
